YE3-132S1-2-5.5KW-380V-IP55

YE3 series of motor housings are made of high strengthened gray cast iron, the coil is made of high quality corrosion-resistant copper wire. The protection of the housing is IP55, which meets the requirements of GB/T4942.1 and IEC60034-5. The mounting dimensions meet with the international standards of IEC60072 and GB/T4772.1, and the cooling types are IC411 and IC416. This series of motor are suitable for continuous working duty (S1), having the characteristics of low loss, high efficiency, compact structure, stable operation, low vibration, low noise, long service life, convenient use and maintenance, etc. They can be widely mounted in machine tools, water pumps, fans, compressors, reducers, and also suitable for many mechanical transmission equipments, such as transportation, mixing, printing, agricultural machinery, food, etc.

A szálláslekérdezés elküldése

Letöltés

Leírás

Műszaki paraméterek

product-482-152

	H132
	5.5KW
	380V, 400V, 415V, 460V, 490V, 660V, 690V
	50Hz, 60Hz
	2P, 4P, 6P, 8P, 10P, 12P
	3000rpm
	IC411
	IP55
	F(155 degree ), H(180 degree )
	S1, S4, S5, S6, S9
	B3/ B5/ B35/ V1

	IE3

The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising all national electrotechnical committees (IEC National Committees). The object of IEC is to promote international co-operation on all questions concerning standardization in the electrical and electronic fields. To this end and in addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as "IEC Publication(s)"). Their preparation is entrusted to technical committees; any IEC National Committee interested in the subject dealt with may participate in this preparatory work. International, governmental and non- governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely with the International Organization for Standardization (ISO) in accordance with conditions determined by agreement between the two organizations.

Népszerű tags: ye3-132s1-2-5.5kw-380v-ip55, China, suppliers, manufacturers, factory, customized , quotation, low price, in stock, made in China

												No-Load Noise
												No-Load Noise
同步转速Synchronous Speed 3000r/min
YE3-132S1-2	5.5	380	10.6	2945	89.2	0.88	2.0	8.5	2.3	17.5	0.02	79	63
